Specification
overview:
Download the Evaluation
boards
user
guide here
!
- Power
Source Options:
- AA
size battery
- USB
- External
5V DC power supply.
- 20
Way JTAG connector.
-
16M (8M x 16) Bytes of SDRAM.
-
8M (4M x 16) Bytes of FLASH.
=>Expandable to 16M (8M x 16) Bytes of FLASH.
-
1 x LCD Module with Epson S1D15605 built in.
-
1 x SD Card connector.
-
1 x USB connector (USB B Receptacle Connector for
USB Device).
-
1 x UART (RS232) physical interface circuits connected
to standard PC style DB9 male connector.
-
1 x Headphone jack (3.5mm).
- (Not
installed) Additional Headphone jack (3.5mm).
-
2 x 10, 2 x 20 pin break-out headers.
-
Reset pushbutton switch.
-
Mode Selection pushbutton switches.
-
Start, Stop pushbutton switches.
-
1 x User output LED.
-
3 x Power Supply Status LEDs.
-
Small prototyping area consisting of an area of 0.1
inch spaced through holes with easy access to ground
and 3.3V power supply points.
